Black mesh panel security fencing along a commercial boundary

Panel fencing

Security Mesh Fencing

Minimalist, flat panels with high rigidity: 656 and 868 twin wire mesh, and 358 high-security mesh.

Shop 656 twin wire mesh Request A Quote

Security mesh panels have no ribs. Twin wire panels are reinforced with double horizontal wires of a larger gauge, giving a flat, rigid and durable structure. 358 mesh uses a very tight 76.2 x 12.7 mm aperture for sites that need the highest resistance to climbing.

  • Security and style

    A classic security fence that meets today's standards, with colours and post systems to suit the surroundings.

  • Versatility

    Ideal for company premises, factories, industrial and public buildings, car parks and development sites, on flat or sloping ground, above ground level or on a concrete gravel board.

  • Many installation systems

    Twin wire panels fit several post types and fixing systems, so the fence can be matched to the site and the level of security needed.

Technical data

656 and 868 twin wire mesh

656 panels are spot welded with double 6 mm horizontal wires and 5 mm vertical wires. 868 (heavy duty) uses double 8 mm horizontal wires and 6 mm vertical wires.

Panels finish with 30 mm extended wire ends at the top or bottom. 868 is also the infill we weld into WSP 130 sliding gates, so fence and gate match.

Shop 656 twin wire mesh
Dimensions (mm) 656 868 (heavy duty)
Double horizontal wires (galvanised) 2 x 6 2 x 8
Double horizontal wires (coated) 2 x 6 2 x 8
Vertical wire (galvanised) 4.8 5.9
Vertical wire (coated) 5.0 6.0
Mesh size 50 x 200 50 x 200
Panel width 2500 (51 wires) 2500 (51 wires)
Heights in stock 1830, 2030, 2230, 2430 1830, 2030, 2430

High-security, anti-climb

358 security mesh

358 is named after its 3" x ½" mesh on 8-gauge (4 mm) wire. The 76.2 x 12.7 mm aperture leaves almost nothing to grip, so the fence is very hard to climb, and the close wire spacing makes it hard to cut. Panels are held by full-height clamp bars with security fixings.

It's the usual choice for utilities, substations, data centres, transport and other critical sites. Ask us about taller fences, double-skin panels and anti-climb toppers.

Request A Quote
Dimensions (mm) 358 security mesh
Mesh aperture 76.2 x 12.7 (3" x ½")
Wire diameter 4.0
Weld Every intersection
Panel width 2515 approx.
Typical heights 2000 – 3600
Fixing Full-height clamp bar with security fixings

Installation systems

  • CLIP

    Twin wire. A classic solution: 60 x 40 post with a plastic cap and hooks with threaded holes for the panel fixings.

  • CLAMP BAR

    Twin wire. High aesthetic quality: 60 x 40 post with a plastic or aluminium cap, panels held along their full height.

  • 358 clamp bar

    358. Full-height clamp bar with security fixings along the panel edges.

Panels can be installed on flat or sloping ground, directly above ground level or on a concrete gravel board. Posts can be concreted in or bolted to a concrete foundation using base plates.

A complete fence system

Our fences are complete systems: panels, posts and fixings, with matching sliding gates, single- and double-leaf gates and pedestrian gates, plus access control. One supplier for the whole perimeter, with technical support for trade installers.

Galvanised + powder coated

Colour & finish

Panels are welded from raw wire, then hot-dip galvanised (EN ISO 1461) or electro-galvanised (EN ISO 2081), and finished with a polyester powder coat (EN 10244-2). Zinc and powder coat together greatly extend the life of the fence, and coated panels carry a 10-year corrosion protection warranty. Panels are manufactured to EN 10223-7.

Colour RAL code
Gentian blue RAL 5010
Moss green RAL 6005
Anthracite grey RAL 7016
Stone grey RAL 7030
Window grey RAL 7040
Chocolate brown RAL 8017
Jet black RAL 9005
Traffic white RAL 9016
Hot-dip galvanised No powder coat

Complete the perimeter

Get a security mesh quote
